Backstage Cost Insights Plugin

Install the frontend package

Copy

# run from your Backstage repo root
yarn --cwd packages/app add @backstage-community/plugin-cost-insights

Add required config

Add the required engineer cost. You can add optional fields later.

Copy

# app-config.yaml
costInsights:
  engineerCost: 200000

Optional examples

Copy

# app-config.yaml
costInsights:
  engineerCost: 200000

  products:
    productA:
      name: Some Cloud Product
      icon: storage
    productB:
      name: Some Other Cloud Product
      icon: data

  metrics:
    metricA:
      name: Metric A
      default: true
    metricB:
      name: Metric B

  baseCurrency:
    locale: nl-NL
    options:
      currency: EUR
      minimumFractionDigits: 3

  currencies:
    engineers:
      label: Engineers
      unit: engineers
    usd:
      label: USD
      kind: USD
      unit: dollars
      prefix: $
      rate: 1

  engineerThreshold: 0.5

Implement a Cost Insights client

You need a client that implements the CostInsightsApi. Start simple. You can replace the fetchers with real calls later. Keep this in the app package.

Copy

// packages/app/src/costInsights/CostInsightsClient.ts
import {
  CostInsightsApi,
  costInsightsApiRef,
  Duration,
  ExampleCostInsightsClient,
  Cost,
  MetricData,
  Entity,
  Project,
  Group,
} from '@backstage-community/plugin-cost-insights';

export class CostInsightsClient implements CostInsightsApi {
  // start with the example client to get the UI working
  private readonly demo = new ExampleCostInsightsClient();

  async getLastCompleteBillingDate(): Promise<string> {
    return this.demo.getLastCompleteBillingDate();
  }

  async getUserGroups(userId: string): Promise<Group[]> {
    return this.demo.getUserGroups(userId);
  }

  async getGroupProjects(group: string): Promise<Project[]> {
    return this.demo.getGroupProjects(group);
  }

  async getGroupDailyCost(group: string, intervals: string): Promise<Cost> {
    return this.demo.getGroupDailyCost(group, intervals);
  }

  async getProjectDailyCost(project: string, intervals: string): Promise<Cost> {
    return this.demo.getProjectDailyCost(project, intervals);
  }

  async getDailyMetricData(metric: string, intervals: string): Promise<MetricData> {
    return this.demo.getDailyMetricData(metric, intervals);
  }

  async getProductInsights(options: {
    product: string;
    group: string;
    intervals: string;
    project: string | null;
  }): Promise<Entity> {
    return this.demo.getProductInsights(options);
  }

  async getCatalogEntityDailyCost(entityRef: string, intervals: string): Promise<Cost> {
    return this.demo.getCatalogEntityDailyCost(entityRef, intervals);
  }

  async getAlerts(group: string) {
    return this.demo.getAlerts(group);
  }
}

You can keep the example client while you build your backend. Replace the demo calls with your fetch code when ready.

Wire the API into the app

Copy

// packages/app/src/api.ts
import { createApiFactory } from '@backstage/core-plugin-api';
import { costInsightsApiRef } from '@backstage-community/plugin-cost-insights';
import { CostInsightsClient } from './costInsights/CostInsightsClient';

export const apis = [
  createApiFactory({
    api: costInsightsApiRef,
    deps: {},
    factory: () => new CostInsightsClient(),
  }),
];

Add the Cost Insights page and route

Copy

// packages/app/src/App.tsx
import React from 'react';
import { FlatRoutes } from '@backstage/core-app-api';
import { Route } from 'react-router';
import { CostInsightsPage } from '@backstage-community/plugin-cost-insights';

export const AppRoutes = () => (
  <FlatRoutes>
    {/* other routes */}
    <Route path="/cost-insights" element={<CostInsightsPage />} />
  </FlatRoutes>
);

Add a sidebar entry

Copy

// packages/app/src/components/Root/Root.tsx
import React, { PropsWithChildren } from 'react';
import MonetizationOn from '@material-ui/icons/MonetizationOn';
import {
  SidebarPage,
  Sidebar,
  SidebarItem,
  SidebarLogo,
  SidebarGroup,
  SidebarDivider,
  SidebarScrollWrapper,
  SidebarSpace,
  SidebarSettings,
} from '@backstage/core-components';
import { UserSettingsSignInAvatar } from '@backstage/plugin-user-settings';

export const Root = ({ children }: PropsWithChildren<{}>) => (
  <SidebarPage>
    <Sidebar>
      <SidebarLogo />
      {/* your existing groups */}
      <SidebarDivider />
      <SidebarScrollWrapper>
        <SidebarItem icon={MonetizationOn} to="cost-insights" text="Cost Insights" />
      </SidebarScrollWrapper>
      <SidebarDivider />
      <SidebarGroup label="Settings" icon={<UserSettingsSignInAvatar />} to="/settings">
        <SidebarSettings />
      </SidebarGroup>
      <SidebarSpace />
    </Sidebar>
    {children}
  </SidebarPage>
);

Show costs on entity pages

You can show per entity spend in your catalog pages.

Copy

// packages/app/src/components/catalog/EntityPage.tsx
import React from 'react';
import { Grid } from '@material-ui/core';
import { EntitySwitch, isKind } from '@backstage/plugin-catalog';
import { EntityCostInsightsContent } from '@backstage-community/plugin-cost-insights';

export const OverviewContent = () => (
  <Grid container spacing={3}>
    {/* other cards */}
    <Grid item xs={12}>
      <EntitySwitch>
        <EntitySwitch.Case if={isKind('Component')}>
          <EntityCostInsightsContent />
        </EntitySwitch.Case>
      </EntitySwitch>
    </Grid>
  </Grid>
);

New frontend system setup

If your app uses the new frontend system, use the alpha export. Keep your client in the api registry the same way.

Copy

// packages/app/src/App.tsx
import React from 'react';
import { createApp } from '@backstage/frontend-app-api';
import { createApiFactory } from '@backstage/core-plugin-api';
import costInsights from '@backstage-community/plugin-cost-insights/alpha';
import { costInsightsApiRef } from '@backstage-community/plugin-cost-insights';
import MonetizationOn from '@material-ui/icons/MonetizationOn';
import { CostInsightsClient } from './costInsights/CostInsightsClient';

const app = createApp({
  features: [
    costInsights.provide('page:cost-insights', { path: '/cost-insights' }),
    costInsights.provide('nav-item:cost-insights', {
      title: 'Cost Insights',
      icon: MonetizationOn,
      routeRef: costInsights.routes.root,
    }),
    costInsights.provide(
      'api:cost-insights',
      createApiFactory({
        api: costInsightsApiRef,
        deps: {},
        factory: () => new CostInsightsClient(),
      }),
    ),
  ],
});

export default app.createRoot();

Provide a backend with the new backend system

The plugin does not ship a backend. You can add a small backend module that exposes the cost data your client needs. This keeps provider credentials off the browser.

Install any SDKs you plan to call from the backend. Here is an example for the AWS Cost Explorer client.

Copy

yarn --cwd packages/backend add @aws-sdk/client-cost-explorer

Create a backend module that mounts a router.

Copy

// packages/backend/src/plugins/costInsights.ts
import { Router } from 'express';
import { CostExplorerClient, GetCostAndUsageCommand } from '@aws-sdk/client-cost-explorer';

export async function createCostInsightsRouter(): Promise<Router> {
  const router = Router();

  const ce = new CostExplorerClient({
    region: process.env.AWS_REGION,
    credentials: {
      accessKeyId: process.env.AWS_ACCESS_KEY_ID ?? '',
      secretAccessKey: process.env.AWS_SECRET_ACCESS_KEY ?? '',
    },
  });

  router.get('/group-daily-cost', async (req, res) => {
    const { accountId, start, end } = req.query as Record<string, string>;
    const cmd = new GetCostAndUsageCommand({
      TimePeriod: { Start: start, End: end },
      Metrics: ['UnblendedCost'],
      Filter: { Dimensions: { Key: 'LINKED_ACCOUNT', Values: [accountId] } },
      Granularity: 'DAILY',
    });

    const data = await ce.send(cmd);
    // map AWS response to the Cost type expected by the frontend
    const aggregation =
      data.ResultsByTime?.map(d => ({
        date: d.TimePeriod?.Start ?? '',
        amount: Number(d.Total?.UnblendedCost?.Amount ?? 0),
      })) ?? [];

    res.json({ aggregation });
  });

  return router;
}

Copy

// packages/backend/src/index.ts
import { createBackend } from '@backstage/backend-defaults';
import { createCostInsightsRouter } from './plugins/costInsights';

const backend = createBackend();

backend.addRouter('/api/cost-insights', await createCostInsightsRouter());

backend.start();

Point your frontend client to this backend route. Replace the demo calls.

Copy

// packages/app/src/costInsights/CostInsightsClient.ts
export class CostInsightsClient implements CostInsightsApi {
  async getGroupDailyCost(group: string, intervals: string): Promise<Cost> {
    // pick your own mapping from group to account id
    const accountId = group;
    const [start, end] = intervals.split('/');
    const res = await fetch(
      `/api/cost-insights/group-daily-cost?accountId=${encodeURIComponent(
        accountId,
      )}&start=${encodeURIComponent(start)}&end=${encodeURIComponent(end)}`,
    );
    if (!res.ok) throw new Error(`Failed to fetch group daily cost`);
    return await res.json();
  }

  // implement the other methods the same way
}

Provide a backend with the classic backend

Create a router and mount it under the api path.

Copy

// packages/backend/src/plugins/costInsights.ts
import { Router } from 'express';

export default async function createPlugin(): Promise<Router> {
  const router = Router();

  router.get('/ping', async (_req, res) => {
    res.json({ ok: true });
  });

  // add your endpoints here
  // for example /group-daily-cost like in the new backend example above

  return router;
}

Mount it in the backend index.

Copy

// packages/backend/src/index.ts
import costInsights from './plugins/costInsights';

// inside main bootstrap
const apiRouter = Router();
apiRouter.use('/cost-insights', await costInsights());
app.use('/api', apiRouter);

Update your frontend client to call /api/cost-insights/... like in the new backend example.

Build real data into the client over time

You can implement the CostInsightsApi methods against any provider or internal billing store.

If you use AWS, the AWS SDK client can answer the methods your frontend expects. The Cost Explorer GetCostAndUsage command gives you daily totals and grouped totals. Cache where possible to keep requests low.

Copy

// example snippet inside your backend
const cmd = new GetCostAndUsageCommand({
  TimePeriod: { Start: '2021-01-01', End: '2021-02-01' },
  Metrics: ['UnblendedCost'],
  Granularity: 'DAILY',
  GroupBy: [{ Type: 'DIMENSION', Key: 'SERVICE' }],
});
const data = await ce.send(cmd);

Tips while you wire this up

Start with ExampleCostInsightsClient so your page renders
Replace methods one by one with calls to your backend
Keep engineerCost in config up to date so the UI can compute changes
Add products and metrics when you have data to back them

What the plugin exports that you can use

Import these from the app where you need them.

Copy

// page
import { CostInsightsPage } from '@backstage-community/plugin-cost-insights';

// api ref and types
import {
  costInsightsApiRef,
  CostInsightsApi,
  Duration,
  EntityCostInsightsContent,
} from '@backstage-community/plugin-cost-insights';

// new frontend system
import costInsights from '@backstage-community/plugin-cost-insights/alpha';

Place CostInsightsPage in your top level routes so everyone can reach it. Place EntityCostInsightsContent in your entity pages so teams can see cost near their components.
